803 Interconnect Machined Pin Socket
Overview
Description:
Compliant Tail Press Fit Socket
Accepts .025"-.037" (0,635-0,940mm) dia leads
Rows:
Double Row
.100" (2,540mm) Pitch
Mounting Type:
Press-Fit Into a Plated Through Hole
Packaging Options:
Packaged in Box or Tube
Product Family:
PCB Connector
Mates With:
802-XX-XXX-10-001000
802-XX-XXX-10-002000
803-XX-XXX-20-001000
802-XX-XXX-30-001000
802-XX-XXX-61-001000
802-XX-XXX-62-001000
319-10-XXX-XX-XXXXXX
330-10-XXX-XX-XXXXXX
803 Interconnect Machined Pin Socket
Overview
Description:
Compliant Tail Press Fit Socket
Accepts .025"-.037" (0,635-0,940mm) dia leads
Rows:
Double Row
.100" (2,540mm) Pitch
Mounting Type:
Press-Fit Into a Plated Through Hole
Packaging Options:
Packaged in Box or Tube
Product Family:
PCB Connector
Mates With:
802-XX-XXX-10-001000
802-XX-XXX-10-002000
803-XX-XXX-20-001000
802-XX-XXX-30-001000
802-XX-XXX-61-001000
802-XX-XXX-62-001000
319-10-XXX-XX-XXXXXX
330-10-XXX-XX-XXXXXX
Products
Narrow Results by:
| Part No. | Priority | In Stock | In Stock Sort | Plating Code | RoHS | No. Pins | Collapsed Product Detail |
|---|
