Edge Mounted Pins for Board Interconnects
1160 Solder Cup Terminal Pin
Overview
Description:
Solder Cup Terminal Pin
Wire Termination:
Soldercup up to 16 AWG
Mounting Feature:
Press-Fit into a Non-Plated Through Hole (NPTH) or Insulator
Mounting Hole:
.080" (2,032mm)
Tail Type:
Soldertail
Tail Diameter: .060" (1,524mm)
Alternate Mounting:
Through-Hole Soldertail Mount
Alternate Mounting Hole:
.064" (1,626mm)
1160 Solder Cup Terminal Pin
Overview
Description:
Solder Cup Terminal Pin
Wire Termination:
Soldercup up to 16 AWG
Mounting Feature:
Press-Fit into a Non-Plated Through Hole (NPTH) or Insulator
Mounting Hole:
.080" (2,032mm)
Tail Type:
Soldertail
Tail Diameter: .060" (1,524mm)
Alternate Mounting:
Through-Hole Soldertail Mount
Alternate Mounting Hole:
.064" (1,626mm)
